Portenta Breakout ARDUINO PRO

Overview Portenta Breakout board is designed to help hardware engineers and makers to prototype and help test devices connections and capacity within the Portenta family boards (e.g. the Portenta H7). It makes all high-density connectors’ signals individually accessible, making it quick and easy to connect and test external hardware components and devices as normally needed during development in the lab. Target areas Prototyping Application examples This product is designed to work alongside the Portenta family. Please check the Getting Started guide of your Portenta board. Product Development: The Portenta Breakout board reduces development time for industrial grade solution automation based on the Portenta line. Technical Education: The Portenta Breakout board can act as the first point of entry for technician education in industrial grade control and embedded systems. Features Power ON Button Boot mode DIP switch Connectors - USBA - RJ45 up to 1Gb/s - Micro SD card - MIPI 20T JTAG with trace capability Power - CR2032 RTC Lithium Battery backup - External power terminal block I/O - Break out all Portenta High Density connector signals - Male/female HD connectors allow interposing breakout between Portenta and shield to debug signals Compatibility - Standard Portenta High Density connector pinout Safety information - Class A Tech specs USB port USBA Ethernet RJ45 up to 1Gb/s (Supported on Portenta X8 only) Memory slot Micro SD card Debug MIPI 20T JTAG with trace capability Connectors HD male/female RTC power battery CR2032 Length 164 mm Width 72 mm Weight 0,069 Kg Documentation Study how the Portenta Breakout Carrier works using following files: SCHEMATICS IN .PDF DATASHEET IN .PDF
